Flat Die Pellet Mill

Flat Die Pellet Mill Introduction

Flat die pellet mill or flat die pellet machine uses two-stage driving of belt and worm and gear, with smooth running, low noise, gravity feeding, no blocking, spindle speeds of roughly 60rpm, and line speeds of roller roughly 2.5m/s, so flat die pellet machine can effectively remove the gas and increase the tightness of product.

The lower line speeds can reduce noise and wear in runtime, so the flat die pellet mill can produce products with high fat and high molasses. In addition, the roller bearing has lasting lubrication and special seal, which can prevent lubricant contaminated and reduce the loss of lubricant in the pelleting process.

Flat Die Pellet Mill Features

1. The finished products of the flat die wood pellet machine made by Fote Machinery-one of China famous flat die pellet mill suppliers is dried without drying (The moisture of raw material is not less than 13% of the national export standards). Fote flat die pellet mill is equipped with differential mechanism, Cardan drive, electrical machine or diesel engine, with low power, high output, and easy to operate.
2. Fote flat die pellet mill uses new technology of extrusion-granulation, polishing and finishing, which thoroughly solves the traditional granulation process problems of low organic ingredients (around 30%), difficult to pellet, raw materials required to be dried, and other critical technical problems.
3. Fote flat die pellet mill machine can produce ball type organic fertilizer, organic and inorganic fertilizer and bio-organic fertilizer, with smooth and rounded grain, high strength, good fluidity, etc.
4. Fote flat die pellet mill machine uses unique three-in-one technology to complete the process of low temperature drying, cooling and screening in one time, with low equipment investment and low running cost. Microbial survival rate can be up to 90% or above it.

Flat Die Pellet Mill Working Principle

When the flat die pellet mill works, the compression roller and stamper make relative motion to compress and compact materials into die holes, and then be cut into grain or block through floccitation. Flat die pellet mill is divided into two transmission forms: 1. The mill frame is fixed on the enclosure, the spindle drives the stamper to rotate; 2. The compression moulding is fixed, the spindle drives pressure roller to work, while the pressure roller does both revolution and rotation. The two driving models of flat die wood pellet machine have the same principle.
